插线式接线头
■ PC和PP工程塑料成型外壳，UL94V-2阻燃等级，额定温度T85(IEC)、105℃(UL)
■ 由镀锡高导电性铜板和不锈钢弹簧组成的弹簧力接线端子
■ 电线剥除绝缘皮后直接插入线槽即可固定
■ 适用单股、多股硬铜导线及焊锡多股铜导线
■ 插入力小，连接快速方便
■ 颜色编码的透明外壳可清楚地检视导线连接状况
■ 符合IEC/EN60998、GB/T13140和UL 486C标准规范
■ 适用于灯饰配线和建筑水电工程电气接线盒内配线
文件名称
颜色
极数
电气规格
适用电线
包装单位
操作
PC224
橙色
4
24A, 450V, T85℃
600V, 105°C
600V, 105°C
0,2-2,5mm², Rigid
24-12 AWG, Sol
24-14 AWG, Tin-bonded Str
24-12 AWG, Sol
24-14 AWG, Tin-bonded Str
5,000/箱
(10袋,500/袋)
(10袋,500/袋)
PC212U
红色
2
24A, 450V, T85℃
600V, 105°C (221°F)
600V, 105°C (221°F)
0,2-2,5mm², Rigid
24-12 AWG, Sol
24-14 AWG, Tin-bonded Str
24-12 AWG, Sol
24-14 AWG, Tin-bonded Str
10,000/箱
(10袋,1000/袋)
(10袋,1000/袋)
PC213U
橙色
3
24A, 450V, T85℃
600V, 105°C
600V, 105°C
0,2-2,5 mm², Rigid
24-12 AWG, Sol
24-14 AWG, Tin-bonded Str
24-12 AWG, Sol
24-14 AWG, Tin-bonded Str
10,000/箱
(10袋,1000/袋)
(10袋,1000/袋)
PC214U
黄色
4
24A, 450V, T85℃
600V, 105°C
600V, 105°C
0,2-2,5 mm², Rigid
24-12 AWG, Sol
24-14 AWG, Tin-bonded Str
24-12 AWG, Sol
24-14 AWG, Tin-bonded Str
5,000/箱
(10袋,500/袋)
(10袋,500/袋)
PC215U
灰色
5
24A, 450V, T85℃
600V, 105°C
600V, 105°C
0,2-2,5 mm², Rigid
24-12 AWG, Sol
24-14 AWG, Tin-bonded Str
24-12 AWG, Sol
24-14 AWG, Tin-bonded Str
5,000/箱
(10袋,500/袋)
(10袋,500/袋)
PC332
红色
2
32A/24A, 450V, T85℃
600V, 105°C (221°F)
600V, 105°C (221°F)
0,5-4,0 mm², Rigid Sol
0,5-2,5 mm², Rigid Str
22-12 AWG, Sol
20-12 AWG, Str
22-14 AWG, Tin-bonded Str
0,5-2,5 mm², Rigid Str
22-12 AWG, Sol
20-12 AWG, Str
22-14 AWG, Tin-bonded Str
100/盒，10,000/箱
(10袋,1000/袋)
(10袋,1000/袋)
PC333
橙色
3
32A/24A, 450V, T85℃
600V, 105°C (221°F)
600V, 105°C (221°F)
0,5-4,0 mm², Rigid Sol
0,5-2,5 mm², Rigid Str
22-12 AWG, Sol
20-12 AWG, Str
22-14 AWG, Tin-bonded Str
0,5-2,5 mm², Rigid Str
22-12 AWG, Sol
20-12 AWG, Str
22-14 AWG, Tin-bonded Str
100/盒，10,000/箱
(10袋,1000/袋)
(10袋,1000/袋)
PC334
黄色
4
32A/24A, 450V, T85℃
600V, 105°C (221°F)
600V, 105°C (221°F)
0,5-4,0 mm², Rigid Sol
0,5-2,5 mm², Rigid Str
22-12 AWG, Sol
20-12 AWG, Str
22-14 AWG, Tin-bonded Str
0,5-2,5 mm², Rigid Str
22-12 AWG, Sol
20-12 AWG, Str
22-14 AWG, Tin-bonded Str
100/盒，50,00/箱
(10袋,500/袋)
(10袋,500/袋)
PC335
蓝色
5
32A/24A, 450V, T85℃
600V, 105°C (221°F)
600V, 105°C (221°F)
0,5-4,0 mm², Rigid Sol
0,5-2,5 mm², Rigid Str
22-12 AWG, Sol
20-12 AWG, Str
22-14 AWG, Tin-bonded Str
0,5-2,5 mm², Rigid Str
22-12 AWG, Sol
20-12 AWG, Str
22-14 AWG, Tin-bonded Str
100/盒，50,00/箱
(10袋,500/袋)
(10袋,500/袋)
PC863
红色
3
41A, 450V, T85℃
2,5-6,0mm² , Rigid
50/盒，25,00/箱
(10袋,250/袋)
(10袋,250/袋)
